APG06060 M6 x 60 Ø6 10 100 B 200 1.200 8423533751478 tfix - Épaisseur max. à fixer 10 SW - Schlüsselweite 10 df - Ø Élément à fixer 7 Tins - Tins - 7 hef - Profondeur effective 40 hnom - Min. profondeur cheville 46 h1 - Profondeur min. de perçade 50 d0 - Ø Foret 6 hmin - Min. épaisseur du support 100 L - Longueur 60 APG06070 M6 x 70 Ø6 20 100 C 200 1.200 8423533751485 tfix - Épaisseur max. à fixer 20 SW - Schlüsselweite 10 df - Ø Élément à fixer 7 Tins - Tins - 7 hef - Profondeur effective 40 hnom - Min. profondeur cheville 46 h1 - Profondeur min. de perçade 50 d0 - Ø Foret 6 hmin - Min. épaisseur du support 100 L - Longueur 70 APG06100 M6 x 100 Ø6 50 100 E 200 800 8423533751492 tfix - Épaisseur max. à fixer 50 SW - Schlüsselweite 10 df - Ø Élément à fixer 7 Tins - Tins - 7 hef - Profondeur effective 40 hnom - Min. profondeur cheville 46 h1 - Profondeur min. de perçade 50 d0 - Ø Foret 6 hmin - Min. épaisseur du support 100 L - Longueur 100 APG08050 M8 x 50 Ø8 2 100 A 100 800 8423533749734 tfix - Épaisseur max. à fixer 2 SW - Schlüsselweite 13 df - Ø Élément à fixer 9 Tins - Tins - 15 hef - Profondeur effective 30 hnom - Min. profondeur cheville 37 h1 - Profondeur min. de perçade 40 d0 - Ø Foret 8 hmin - Min. épaisseur du support 100 L - Longueur 50 APG08060 M8 x 60 Ø8 12 100 B 100 800 8423533751447 tfix - Épaisseur max. à fixer 12 SW - Schlüsselweite 13 df - Ø Élément à fixer 9 Tins - Tins - 15 hef - Profondeur effective 30 hnom - Min. profondeur cheville 37 h1 - Profondeur min. de perçade 40 d0 - Ø Foret 8 hmin - Min. épaisseur du support 100 L - Longueur 60 APG08075 M8 x 75 Ø8 9 100 C 100 600 8423533725448 tfix - Épaisseur max. à fixer 9 SW - Schlüsselweite 13 df - Ø Élément à fixer 9 Tins - Tins - 15 hef - Profondeur effective 48 hnom - Min. profondeur cheville 55 h1 - Profondeur min. de perçade 60 d0 - Ø Foret 8 hmin - Min. épaisseur du support 100 L - Longueur 75 APG08095 M8 x 95 Ø8 29 100 E 100 600 8423533749741 tfix - Épaisseur max. à fixer 29 SW - Schlüsselweite 13 df - Ø Élément à fixer 9 Tins - Tins - 15 hef - Profondeur effective 48 hnom - Min. profondeur cheville 55 h1 - Profondeur min. de perçade 60 d0 - Ø Foret 8 hmin - Min. épaisseur du support 100 L - Longueur 95 APG08115 M8 x 115 Ø8 49 100 G 100 400 8423533749758 tfix - Épaisseur max. à fixer 49 SW - Schlüsselweite 13 df - Ø Élément à fixer 9 Tins - Tins - 15 hef - Profondeur effective 48 hnom - Min. profondeur cheville 55 h1 - Profondeur min. de perçade 60 d0 - Ø Foret 8 hmin - Min. épaisseur du support 100 L - Longueur 115 APG10070 M10 x 70 Ø10 5 100 C 100 400 8423533751454 tfix - Épaisseur max. à fixer 5 SW - Schlüsselweite 17 df - Ø Élément à fixer 12 Tins - Tins - 40 hef - Profondeur effective 45 hnom - Min. profondeur cheville 53 h1 - Profondeur min. de perçade 60 d0 - Ø Foret 10 hmin - Min. épaisseur du support 100 L - Longueur 70 APG10090 M10 x 90 Ø10 10 120 E 100 400 8423533725479 tfix - Épaisseur max. à fixer 10 SW - Schlüsselweite 17 df - Ø Élément à fixer 12 Tins - Tins - 40 hef - Profondeur effective 60 hnom - Min. profondeur cheville 68 h1 - Profondeur min. de perçade 75 d0 - Ø Foret 10 hmin - Min. épaisseur du support 120 L - Longueur 90 APG10105 M10 x 105 Ø10 25 120 F 50 300 8423533749765 tfix - Épaisseur max. à fixer 25 SW - Schlüsselweite 17 df - Ø Élément à fixer 12 Tins - Tins - 40 hef - Profondeur effective 60 hnom - Min. profondeur cheville 68 h1 - Profondeur min. de perçade 75 d0 - Ø Foret 10 hmin - Min. épaisseur du support 120 L - Longueur 105 APG10115 M10 x 115 Ø10 35 120 G 50 200 8423533749772 tfix - Épaisseur max. à fixer 35 SW - Schlüsselweite 17 df - Ø Élément à fixer 12 Tins - Tins - 40 hef - Profondeur effective 60 hnom - Min. profondeur cheville 68 h1 - Profondeur min. de perçade 75 d0 - Ø Foret 10 hmin - Min. épaisseur du support 120 L - Longueur 115 APG10135 M10 x 135 Ø10 55 120 H 50 200 8423533749789 tfix - Épaisseur max. à fixer 55 SW - Schlüsselweite 17 df - Ø Élément à fixer 12 Tins - Tins - 40 hef - Profondeur effective 60 hnom - Min. profondeur cheville 68 h1 - Profondeur min. de perçade 75 d0 - Ø Foret 10 hmin - Min. épaisseur du support 120 L - Longueur 135 APG10165 M10 x 165 Ø10 85 120 K 50 200 8423533749796 tfix - Épaisseur max. à fixer 85 SW - Schlüsselweite 17 df - Ø Élément à fixer 12 Tins - Tins - 40 hef - Profondeur effective 60 hnom - Min. profondeur cheville 68 h1 - Profondeur min. de perçade 75 d0 - Ø Foret 10 hmin - Min. épaisseur du support 120 L - Longueur 165 APG10185 M10 x 185 Ø10 105 120 L 50 150 8423533749802 tfix - Épaisseur max. à fixer 105 SW - Schlüsselweite 17 df - Ø Élément à fixer 12 Tins - Tins - 40 hef - Profondeur effective 60 hnom - Min. profondeur cheville 68 h1 - Profondeur min. de perçade 75 d0 - Ø Foret 10 hmin - Min. épaisseur du support 120 L - Longueur 185 APG12080 M12 x 80 Ø12 4 100 D 50 300 8423533749819 tfix - Épaisseur max. à fixer 4 SW - Schlüsselweite 19 df - Ø Élément à fixer 14 Tins - Tins - 60 hef - Profondeur effective 50 hnom - Min. profondeur cheville 60 h1 - Profondeur min. de perçade 65 d0 - Ø Foret 12 hmin - Min. épaisseur du support 100 L - Longueur 80 APG12110 M12 x 110 Ø12 14 140 F 50 200 8423533725523 tfix - Épaisseur max. à fixer 14 SW - Schlüsselweite 19 df - Ø Élément à fixer 14 Tins - Tins - 60 hef - Profondeur effective 70 hnom - Min. profondeur cheville 80 h1 - Profondeur min. de perçade 85 d0 - Ø Foret 12 hmin - Min. épaisseur du support 140 L - Longueur 110 APG12130 M12 x 130 Ø12 34 140 H 50 200 8423533749833 tfix - Épaisseur max. à fixer 34 SW - Schlüsselweite 19 df - Ø Élément à fixer 14 Tins - Tins - 60 hef - Profondeur effective 70 hnom - Min. profondeur cheville 80 h1 - Profondeur min. de perçade 85 d0 - Ø Foret 12 hmin - Min. épaisseur du support 140 L - Longueur 130 APG12150 M12 x 150 Ø12 54 140 I 50 100 8423533749840 tfix - Épaisseur max. à fixer 54 SW - Schlüsselweite 19 df - Ø Élément à fixer 14 Tins - Tins - 60 hef - Profondeur effective 70 hnom - Min. profondeur cheville 80 h1 - Profondeur min. de perçade 85 d0 - Ø Foret 12 hmin - Min. épaisseur du support 140 L - Longueur 150 APG12180 M12 x 180 Ø12 84 140 L 50 150 8423533725554 tfix - Épaisseur max. à fixer 84 SW - Schlüsselweite 19 df - Ø Élément à fixer 14 Tins - Tins - 60 hef - Profondeur effective 70 hnom - Min. profondeur cheville 80 h1 - Profondeur min. de perçade 85 d0 - Ø Foret 12 hmin - Min. épaisseur du support 140 L - Longueur 180 APG12200 M12 x 200 Ø12 104 140 M 50 150 8423533749857 tfix - Épaisseur max. à fixer 104 SW - Schlüsselweite 19 df - Ø Élément à fixer 14 Tins - Tins - 60 hef - Profondeur effective 70 hnom - Min. profondeur cheville 80 h1 - Profondeur min. de perçade 85 d0 - Ø Foret 12 hmin - Min. épaisseur du support 140 L - Longueur 200 APG16125 M16 x 125 Ø16 8 170 G 25 100 8423533725561 tfix - Épaisseur max. à fixer 8 SW - Schlüsselweite 24 df - Ø Élément à fixer 18 Tins - Tins - 100 hef - Profondeur effective 85 hnom - Min. profondeur cheville 97 h1 - Profondeur min. de perçade 105 d0 - Ø Foret 16 hmin - Min. épaisseur du support 170 L - Longueur 125 APG16145 M16 x 145 Ø16 28 170 I 25 100 8423533725578 tfix - Épaisseur max. à fixer 28 SW - Schlüsselweite 24 df - Ø Élément à fixer 18 Tins - Tins - 100 hef - Profondeur effective 85 hnom - Min. profondeur cheville 97 h1 - Profondeur min. de perçade 105 d0 - Ø Foret 16 hmin - Min. épaisseur du support 170 L - Longueur 145 APG16175 M16 x 175 Ø16 58 170 K 25 50 8423533749864 tfix - Épaisseur max. à fixer 58 SW - Schlüsselweite 24 df - Ø Élément à fixer 18 Tins - Tins - 100 hef - Profondeur effective 85 hnom - Min. profondeur cheville 97 h1 - Profondeur min. de perçade 105 d0 - Ø Foret 16 hmin - Min. épaisseur du support 170 L - Longueur 175 APG16220 M16 x 220 Ø16 103 170 O 25 50 8423533725592 tfix - Épaisseur max. à fixer 103 SW - Schlüsselweite 24 df - Ø Élément à fixer 18 Tins - Tins - 100 hef - Profondeur effective 85 hnom - Min. profondeur cheville 97 h1 - Profondeur min. de perçade 105 d0 - Ø Foret 16 hmin - Min. épaisseur du support 170 L - Longueur 220 APG20170 M20 x 170 Ø20 32 200 K 20 40 8423533749888 tfix - Épaisseur max. à fixer 32 SW - Schlüsselweite 30 df - Ø Élément à fixer 22 Tins - Tins - 200 hef - Profondeur effective 100 hnom - Min. profondeur cheville 114 h1 - Profondeur min. de perçade 125 d0 - Ø Foret 20 hmin - Min. épaisseur du support 200 L - Longueur 170 APG20200 M20 x 200 Ø20 62 200 M 20 40 8423533751461 tfix - Épaisseur max. à fixer 62 SW - Schlüsselweite 30 df - Ø Élément à fixer 22 Tins - Tins - 200 hef - Profondeur effective 100 hnom - Min. profondeur cheville 114 h1 - Profondeur min. de perçade 125 d0 - Ø Foret 20 hmin - Min. épaisseur du support 200 L - Longueur 200
