APX08050 M8 x 50 Ø8 2 80 A 100 800 8423533775740 tfix - Max. fixture thickness 2 SW - Installation key 13 df - Ø Element to fix 9 Tins - Torque (Nm) 15 hef - Effective depth 30 hnom - Min. anchor depth 37 h1 - Drill hole depth min. 40 d0 - Ø Drill 8 hmin - Min. substrate thickness 80 L - Lenght 50 APX08075 M8 x 75 Ø8 9 80 C 100 600 8423533775757 tfix - Max. fixture thickness 9 SW - Installation key 13 df - Ø Element to fix 9 Tins - Torque (Nm) 15 hef - Effective depth 48 hnom - Min. anchor depth 55 h1 - Drill hole depth min. 60 d0 - Ø Drill 8 hmin - Min. substrate thickness 80 L - Lenght 75 APX08080 M8 x 80 Ø8 14 80 D 100 600 8423533808127 tfix - Max. fixture thickness 14 SW - Installation key 13 df - Ø Element to fix 9 Tins - Torque (Nm) 15 hnom - Min. anchor depth 55 h1 - Drill hole depth min. 60 d0 - Ø Drill 8 hmin - Min. substrate thickness 80 L - Lenght 80 APX08095 M8 x 95 Ø8 29 80 E 100 600 8423533775764 tfix - Max. fixture thickness 29 SW - Installation key 13 df - Ø Element to fix 9 Tins - Torque (Nm) 15 hef - Effective depth 48 hnom - Min. anchor depth 55 h1 - Drill hole depth min. 60 d0 - Ø Drill 8 hmin - Min. substrate thickness 80 L - Lenght 95 APX08115 M8 x 115 Ø8 49 80 G 100 400 8423533775771 tfix - Max. fixture thickness 49 SW - Installation key 13 df - Ø Element to fix 9 Tins - Torque (Nm) 15 hef - Effective depth 48 hnom - Min. anchor depth 55 h1 - Drill hole depth min. 60 d0 - Ø Drill 8 hmin - Min. substrate thickness 80 L - Lenght 115 APX10090 M10 x 90 Ø10 10 90 E 100 400 8423533775788 tfix - Max. fixture thickness 10 SW - Installation key 17 df - Ø Element to fix 12 Tins - Torque (Nm) 40 hef - Effective depth 60 hnom - Min. anchor depth 68 h1 - Drill hole depth min. 75 d0 - Ø Drill 10 hmin - Min. substrate thickness 90 L - Lenght 90 APX10105 M10 x 105 Ø10 25 90 F 50 300 8423533775795 tfix - Max. fixture thickness 25 SW - Installation key 17 df - Ø Element to fix 12 Tins - Torque (Nm) 40 hef - Effective depth 60 hnom - Min. anchor depth 68 h1 - Drill hole depth min. 75 d0 - Ø Drill 10 hmin - Min. substrate thickness 90 L - Lenght 105 APX10115 M10 x 115 Ø10 35 90 G 50 200 8423533775801 tfix - Max. fixture thickness 35 SW - Installation key 17 df - Ø Element to fix 12 Tins - Torque (Nm) 40 hef - Effective depth 60 hnom - Min. anchor depth 68 h1 - Drill hole depth min. 75 d0 - Ø Drill 10 hmin - Min. substrate thickness 90 L - Lenght 115 APX10135 M10 x 135 Ø10 55 90 H 50 200 8423533775818 tfix - Max. fixture thickness 55 SW - Installation key 17 df - Ø Element to fix 12 Tins - Torque (Nm) 40 hef - Effective depth 60 hnom - Min. anchor depth 68 h1 - Drill hole depth min. 75 d0 - Ø Drill 10 hmin - Min. substrate thickness 90 L - Lenght 135 APX10165 M10 x 165 Ø10 85 90 K 50 200 8423533775825 tfix - Max. fixture thickness 85 SW - Installation key 17 df - Ø Element to fix 12 Tins - Torque (Nm) 40 hef - Effective depth 60 hnom - Min. anchor depth 68 h1 - Drill hole depth min. 75 d0 - Ø Drill 10 hmin - Min. substrate thickness 90 L - Lenght 165 APX10185 M10 x 185 Ø10 105 90 L 50 150 8423533775832 tfix - Max. fixture thickness 105 SW - Installation key 17 df - Ø Element to fix 12 Tins - Torque (Nm) 40 hef - Effective depth 60 hnom - Min. anchor depth 68 h1 - Drill hole depth min. 75 d0 - Ø Drill 10 hmin - Min. substrate thickness 90 L - Lenght 185 APX12080 M12 x 80 Ø12 4 100 D 50 300 8423533775849 tfix - Max. fixture thickness 4 SW - Installation key 19 df - Ø Element to fix 14 Tins - Torque (Nm) 60 hef - Effective depth 50 hnom - Min. anchor depth 60 h1 - Drill hole depth min. 65 d0 - Ø Drill 12 hmin - Min. substrate thickness 100 L - Lenght 80 APX12100 M12 x 100 Ø12 4 105 E 50 200 8423533775856 tfix - Max. fixture thickness 4 SW - Installation key 19 df - Ø Element to fix 14 Tins - Torque (Nm) 60 hef - Effective depth 70 hnom - Min. anchor depth 80 h1 - Drill hole depth min. 85 d0 - Ø Drill 12 hmin - Min. substrate thickness 105 L - Lenght 100 APX12110 M12 x 110 Ø12 14 105 F 50 200 8423533775863 tfix - Max. fixture thickness 14 SW - Installation key 19 df - Ø Element to fix 14 Tins - Torque (Nm) 60 hef - Effective depth 70 hnom - Min. anchor depth 80 h1 - Drill hole depth min. 85 d0 - Ø Drill 12 hmin - Min. substrate thickness 105 L - Lenght 110 APX12120 M12 x 120 Ø12 24 105 G 50 200 8423533775870 tfix - Max. fixture thickness 24 SW - Installation key 19 df - Ø Element to fix 14 Tins - Torque (Nm) 60 hef - Effective depth 70 hnom - Min. anchor depth 80 h1 - Drill hole depth min. 85 d0 - Ø Drill 12 hmin - Min. substrate thickness 105 L - Lenght 120 APX12130 M12 x 130 Ø12 34 105 H 50 200 8423533775887 tfix - Max. fixture thickness 34 SW - Installation key 19 df - Ø Element to fix 14 Tins - Torque (Nm) 60 hef - Effective depth 70 hnom - Min. anchor depth 80 h1 - Drill hole depth min. 85 d0 - Ø Drill 12 hmin - Min. substrate thickness 105 L - Lenght 130 APX12150 M12 x 150 Ø12 54 105 I 50 100 8423533775894 tfix - Max. fixture thickness 54 SW - Installation key 19 df - Ø Element to fix 14 Tins - Torque (Nm) 60 hef - Effective depth 70 hnom - Min. anchor depth 80 h1 - Drill hole depth min. 85 d0 - Ø Drill 12 hmin - Min. substrate thickness 105 L - Lenght 150 APX12180 M12 x 180 Ø12 84 105 L 50 150 8423533775900 tfix - Max. fixture thickness 84 SW - Installation key 19 df - Ø Element to fix 14 Tins - Torque (Nm) 60 hef - Effective depth 70 hnom - Min. anchor depth 80 h1 - Drill hole depth min. 85 d0 - Ø Drill 12 hmin - Min. substrate thickness 105 L - Lenght 180 APX12200 M12 x 200 Ø12 104 105 M 50 150 8423533775917 tfix - Max. fixture thickness 104 SW - Installation key 19 df - Ø Element to fix 14 Tins - Torque (Nm) 60 hef - Effective depth 70 hnom - Min. anchor depth 80 h1 - Drill hole depth min. 85 d0 - Ø Drill 12 hmin - Min. substrate thickness 105 L - Lenght 200 APX12220 M12 x 220 Ø12 124 105 O 25 50 8423533808134 tfix - Max. fixture thickness 124 SW - Installation key 19 df - Ø Element to fix 14 Tins - Torque (Nm) 60 hnom - Min. anchor depth 80 h1 - Drill hole depth min. 85 d0 - Ø Drill 12 hmin - Min. substrate thickness 105 L - Lenght 220 APX12255 M12 x 255 Ø12 159 105 R 25 50 8423533808141 tfix - Max. fixture thickness 159 SW - Installation key 19 df - Ø Element to fix 14 Tins - Torque (Nm) 60 hnom - Min. anchor depth 80 h1 - Drill hole depth min. 85 d0 - Ø Drill 12 hmin - Min. substrate thickness 105 L - Lenght 255 APX16145 M16 x 145 Ø16 28 130 I 25 100 8423533775924 tfix - Max. fixture thickness 28 SW - Installation key 24 df - Ø Element to fix 18 Tins - Torque (Nm) 100 hef - Effective depth 85 hnom - Min. anchor depth 97 h1 - Drill hole depth min. 105 d0 - Ø Drill 16 hmin - Min. substrate thickness 130 L - Lenght 145 APX16175 M16 x 175 Ø16 58 130 K 25 50 8423533775931 tfix - Max. fixture thickness 58 SW - Installation key 24 df - Ø Element to fix 18 Tins - Torque (Nm) 100 hef - Effective depth 85 hnom - Min. anchor depth 97 h1 - Drill hole depth min. 105 d0 - Ø Drill 16 hmin - Min. substrate thickness 130 L - Lenght 175 APX16220 M16 x 220 Ø16 103 130 O 25 50 8423533775948 tfix - Max. fixture thickness 103 SW - Installation key 24 df - Ø Element to fix 18 Tins - Torque (Nm) 100 hef - Effective depth 85 hnom - Min. anchor depth 97 h1 - Drill hole depth min. 105 d0 - Ø Drill 16 hmin - Min. substrate thickness 130 L - Lenght 220 APX16250 M16 x 250 Ø16 133 130 Q 25 50 8423533775955 tfix - Max. fixture thickness 133 SW - Installation key 24 df - Ø Element to fix 18 Tins - Torque (Nm) 100 hef - Effective depth 85 hnom - Min. anchor depth 97 h1 - Drill hole depth min. 105 d0 - Ø Drill 16 hmin - Min. substrate thickness 130 L - Lenght 250 APX20170 M20 x 170 Ø20 32 150 K 20 40 8423533775962 tfix - Max. fixture thickness 32 SW - Installation key 30 df - Ø Element to fix 22 Tins - Torque (Nm) 200 hef - Effective depth 100 hnom - Min. anchor depth 114 h1 - Drill hole depth min. 125 d0 - Ø Drill 20 hmin - Min. substrate thickness 150 L - Lenght 170 APX20200 M20 x 200 Ø20 62 150 M 20 40 8423533775979 tfix - Max. fixture thickness 62 SW - Installation key 30 df - Ø Element to fix 22 Tins - Torque (Nm) 200 hef - Effective depth 100 hnom - Min. anchor depth 114 h1 - Drill hole depth min. 125 d0 - Ø Drill 20 hmin - Min. substrate thickness 150 L - Lenght 200
