Products / Screws / Wood screws / TEX / TEX-ZT

High-performance chipboard screw. Zinc-plated. Tx recess

Lag bolt with TX recess and countersunk head. High performance screw, designed for assemblies where high performance is required, such as the assembly of wooden structures or the installation of hardware. It has an optimised thread pitch and a milled tip for easy penetration into wood. It is made of zinc-plated steel.

ASSESSMENTS AND CERTIFICATES

+ info

CODE	SIZE	Nº RECESS	Min. Order Qty.	Pcs Box	Pcs Masterbox	EAN
TEXZT30016	3 x 16	TX10	2.000	1.000	24.000	8423533465931
	t_fix- Max. fixture thickness8.5 SW - Installation keyTX10 L - Lenght16
TEXZT30020	3 x 20	TX10	2.000	1.000	24.000	8423533465948
	t_fix- Max. fixture thickness12.5 SW - Installation keyTX10 L - Lenght20
TEXZT30025	3 x 25	TX10	2.000	1.000	24.000	8423533465955
	t_fix- Max. fixture thickness17.5 SW - Installation keyTX10 L - Lenght25
TEXZT30030	3 x 30	TX10	2.000	1.000	12.000	8423533465962
	t_fix- Max. fixture thickness22.5 SW - Installation keyTX10 L - Lenght30
TEXZT30035	3 x 35	TX10	2.000	1.000	12.000	8423533465979
	t_fix- Max. fixture thickness27.5 SW - Installation keyTX10 L - Lenght35
TEXZT30040	3 x 40	TX10	2.000	1.000	6.000	8423533465986
	t_fix- Max. fixture thickness32.5 SW - Installation keyTX10 L - Lenght40
TEXZT35012	3,5 x 12	TX15	2.000	1.000	24.000	8423533465993
	t_fix- Max. fixture thickness2,5 SW - Installation keyTX15 L - Lenght12
TEXZT35016	3,5 x 16	TX15	2.000	1.000	24.000	8423533466006
	t_fix- Max. fixture thickness5,5 SW - Installation keyTX15 L - Lenght16
TEXZT35020	3,5 x 20	TX15	2.000	1.000	24.000	8423533466013
	t_fix- Max. fixture thickness9.5 SW - Installation keyTX15 L - Lenght20
TEXZT35025	3,5 x 25	TX15	2.000	1.000	12.000	8423533466020
	t_fix- Max. fixture thickness14.5 SW - Installation keyTX15 L - Lenght25
TEXZT35030	3,5 x 30	TX15	2.000	1.000	12.000	8423533466037
	t_fix- Max. fixture thickness19.5 SW - Installation keyTX15 L - Lenght30
TEXZT35035	3,5 x 35	TX15	2.000	1.000	12.000	8423533466044
	t_fix- Max. fixture thickness24.5 SW - Installation keyTX15 L - Lenght35
TEXZT35040	3,5 x 40	TX15	1.000	500	6.000	8423533466051
	t_fix- Max. fixture thickness29.5 SW - Installation keyTX15 L - Lenght40
TEXZT35045	3,5 x 45	TX15	1.000	500	6.000	8423533466068
	t_fix- Max. fixture thickness34.5 SW - Installation keyTX15 L - Lenght45
TEXZT35050	3,5 x 50	TX15	1.000	500	6.000	8423533466075
	t_fix- Max. fixture thickness39.5 SW - Installation keyTX15 L - Lenght50
TEXZT40016	4 x 16	TX20	2.000	1.000	24.000	8423533466082
	t_fix- Max. fixture thickness4 SW - Installation keyTX20 L - Lenght16
TEXZT40020	4 x 20	TX20	2.000	1.000	12.000	8423533466099
	t_fix- Max. fixture thickness8 SW - Installation keyTX20 L - Lenght20
TEXZT40025	4 x 25	TX20	2.000	1.000	12.000	8423533466105
	t_fix- Max. fixture thickness13 SW - Installation keyTX20 L - Lenght25
TEXZT40030	4 x 30	TX20	2.000	1.000	6.000	8423533466112
	t_fix- Max. fixture thickness18 SW - Installation keyTX20 L - Lenght30
TEXZT40035	4 x 35	TX20	1.000	500	6.000	8423533466129
	t_fix- Max. fixture thickness23 SW - Installation keyTX20 L - Lenght35
TEXZT40040	4 x 40	TX20	1.000	500	6.000	8423533466136
	t_fix- Max. fixture thickness28 SW - Installation keyTX20 L - Lenght40
TEXZT40045	4 x 45	TX20	1.000	500	6.000	8423533466143
	t_fix- Max. fixture thickness33 SW - Installation keyTX20 L - Lenght45
TEXZT40050	4 x 50	TX20	1.000	500	6.000	8423533466150
	t_fix- Max. fixture thickness38 SW - Installation keyTX20 L - Lenght50
TEXZT40055	4 x 55	TX20	500	250	3.000	8423533466167
	t_fix- Max. fixture thickness43 SW - Installation keyTX20 L - Lenght55
TEXZT40060	4 x 60	TX20	500	250	3.000	8423533466174
	t_fix- Max. fixture thickness48 SW - Installation keyTX20 L - Lenght60
TEXZT40070	4 x 70	TX20	500	250	1.500	8423533466181
	t_fix- Max. fixture thickness58 SW - Installation keyTX20 L - Lenght70
TEXZT45030	4,5 x 30	TX20	1.000	500	6.000	8423533437860
	t_fix- Max. fixture thickness12 SW - Installation keyTX20 L - Lenght30
TEXZT45035	4,5 x 35	TX20	1.000	500	6.000	8423533437877
	t_fix- Max. fixture thickness17 SW - Installation keyTX20 L - Lenght35
TEXZT45040	4,5 x 40	TX20	1.000	500	3.000	8423533437884
	t_fix- Max. fixture thickness22 SW - Installation keyTX20 L - Lenght40
TEXZT45050	4,5 x 50	TX20	500	250	3.000	8423533437891
	t_fix- Max. fixture thickness32 SW - Installation keyTX20 L - Lenght50
TEXZT45060	4,5 x 60	TX20	500	250	1.500	8423533437907
	t_fix- Max. fixture thickness42 SW - Installation keyTX20 L - Lenght60
TEXZT45070	4,5 x 70	TX20	500	250	1.500	8423533437914
	t_fix- Max. fixture thickness52 SW - Installation keyTX20 L - Lenght70
TEXZT45080	4,5 x 80	TX20	200	100	1.200	8423533437921
	t_fix- Max. fixture thickness62 SW - Installation keyTX20 L - Lenght80
TEXZT50030	5 x 30	TX25	1.000	500	6.000	8423533437938
	t_fix- Max. fixture thickness10 SW - Installation keyTX25 L - Lenght30
TEXZT50035	5 x 35	TX25	1.000	500	6.000	8423533437945
	t_fix- Max. fixture thickness15 SW - Installation keyTX25 L - Lenght35
TEXZT50040	5 x 40	TX25	1.000	500	6.000	8423533437952
	t_fix- Max. fixture thickness20 SW - Installation keyTX25 L - Lenght40
TEXZT50045	5 x 45	TX25	500	250	3.000	8423533437969
	t_fix- Max. fixture thickness25 SW - Installation keyTX25 L - Lenght45
TEXZT50050	5 x 50	TX25	500	250	3.000	8423533437976
	t_fix- Max. fixture thickness30 SW - Installation keyTX25 L - Lenght50
TEXZT50060	5 x 60	TX25	500	250	2.000	8423533437983
	t_fix- Max. fixture thickness40 SW - Installation keyTX25 L - Lenght60
TEXZT50070	5 x 70	TX25	400	200	1.200	8423533437990
	t_fix- Max. fixture thickness50 SW - Installation keyTX25 L - Lenght70
TEXZT50080	5 x 80	TX25	200	100	1.200	8423533438003
	t_fix- Max. fixture thickness60 SW - Installation keyTX25 L - Lenght80
TEXZT50090	5 x 90	TX25	200	100	1.200	8423533438010
	t_fix- Max. fixture thickness70 SW - Installation keyTX25 L - Lenght90
TEXZT50100	5 x 100	TX25	200	100	1.200	8423533438027
	t_fix- Max. fixture thickness80 SW - Installation keyTX25 L - Lenght100
TEXZT60050	6 x 50	TX30	500	250	2.000	8423533438034
	t_fix- Max. fixture thickness27 SW - Installation keyTX30 L - Lenght50
TEXZT60060	6 x 60	TX30	500	250	1.500	8423533438041
	t_fix- Max. fixture thickness37 SW - Installation keyTX30 L - Lenght60
TEXZT60070	6 x 70	TX30	200	100	1.200	8423533438058
	t_fix- Max. fixture thickness47 SW - Installation keyTX30 L - Lenght70
TEXZT60080	6 x 80	TX30	200	100	1.200	8423533438065
	t_fix- Max. fixture thickness57 SW - Installation keyTX30 L - Lenght80
TEXZT60090	6 x 90	TX30	200	100	800	8423533438072
	t_fix- Max. fixture thickness67 SW - Installation keyTX30 L - Lenght90
TEXZT60100	6 x 100	TX30	200	100	800	8423533438089
	t_fix- Max. fixture thickness77 SW - Installation keyTX30 L - Lenght100
TEXZT60110	6 x 110	TX30	200	100	600	8423533438096
	t_fix- Max. fixture thickness87 SW - Installation keyTX30 L - Lenght110
TEXZT60120	6 x 120	TX30	200	100	600	8423533438102
	t_fix- Max. fixture thickness97 SW - Installation keyTX30 L - Lenght120
TEXZT60130	6 x 130	TX30	100	100	600	8423533438119
	t_fix- Max. fixture thickness107 SW - Installation keyTX30 L - Lenght130
TEXZT60140	6 x 140	TX30	100	100	600	8423533438126
	t_fix- Max. fixture thickness117 SW - Installation keyTX30 L - Lenght140
TEXZT60150	6 x 150	TX30	100	100	600	8423533438133
	t_fix- Max. fixture thickness127 SW - Installation keyTX30 L - Lenght150
TEXZT60160	6 x 160	TX30	100	100	600	8423533438140
	t_fix- Max. fixture thickness137 SW - Installation keyTX30 L - Lenght160
TEXZT60180	6 x 180	TX30	100	100	800	8423533438157
	t_fix- Max. fixture thickness157 SW - Installation keyTX30 L - Lenght180
TEXZT60200	6 x 200	TX30	100	100	300	8423533438164
	t_fix- Max. fixture thickness177 SW - Installation keyTX30 L - Lenght200
TEXZT60220	6 x 220	TX30	100	100	0	8423533438171
	SW - Installation keyTX30 L - Lenght220
TEXZT60240	6 x 240	TX30	100	100	600	8423533438188
	SW - Installation keyTX30 L - Lenght240
TEXZT60260	6 x 260	TX30	100	100	0	8423533438195
	SW - Installation keyTX30 L - Lenght260
TEXZT60280	6 x 280	TX30	100	100	0	8423533438201
	SW - Installation keyTX30 L - Lenght280
TEXZT60300	6 x 300	TX30	100	100	0	8423533438218
	SW - Installation keyTX30 L - Lenght300

Fixing of fittings to timber
Fixing of timber uprights to each other
Joining of metal reinforcements to timber
Timber load-bearing structures
