Self-drilling screw with two wings drill, countersunk head. Zinc-plated. PH recess

CODESIZENº RECESSTHICKNESS MAX.FIXTURE (mm)DRILL CAPACITYMin. Order Qty.Pcs BoxPcs MasterboxEANTechnical info.
ABA48324,8 x 32PH2161,75 - 4,0005006.0008423533194145
  • tfix - Max. fixture thickness16
  • SW - Installation keyPH2
  • L - Lenght32
ABA48384,8 x 38PH2221,75 - 4,0005006.0008423533194862
  • tfix - Max. fixture thickness22
  • SW - Installation keyPH2
  • L - Lenght38
ABA48454,8 x 45PH2291,75 - 4,0005003.0008423533193582
  • tfix - Max. fixture thickness29
  • SW - Installation keyPH2
  • L - Lenght45
ABA48504,8 x 50PH2341,75 - 4,0005003.0008423533191656
  • tfix - Max. fixture thickness34
  • SW - Installation keyPH2
  • L - Lenght50
ABA55385,5 x 38PH2191,75 - 5,0005003.0008423533194220
  • tfix - Max. fixture thickness19
  • SW - Installation keyPH2
  • L - Lenght38
ABA55455,5 x 45PH2261,75 - 5,0005003.0008423533194268
  • tfix - Max. fixture thickness26
  • SW - Installation keyPH2
  • L - Lenght45
ABA55555,5 x 55PH2361,75 - 5,0005003.0008423533191359
  • tfix - Max. fixture thickness36
  • SW - Installation keyPH2
  • L - Lenght55
ABA55655,5 x 65PH2461,75 - 5,0005002.0008423533154910
  • tfix - Max. fixture thickness46
  • SW - Installation keyPH2
  • L - Lenght65
ABA63606,3 x 60PH3402,50 - 6,0002501.5008423533194497
  • tfix - Max. fixture thickness40
  • SW - Installation keyPH2
  • L - Lenght60
ABA63706,3 x 70PH3502,50 - 6,0002501.5008423533194565
  • tfix - Max. fixture thickness50
  • SW - Installation keyPH2
  • L - Lenght70
ABA63856,3 x 85PH3652,50 - 6,0002501.0008423533195074
  • tfix - Max. fixture thickness65
  • SW - Installation keyPH2
  • L - Lenght85
  • Sandwich roofing sheets
  • Sheet metal roofing
  • Roofing sheets
PR208BI14175 CP ABA ABA SZ4
PR208BI14176 CP ABA ABA SZ4
