Products / Anchors / Chemical fixings / CA-QU / CA-QU
CA-QU
CA-QU
Play Video
CA-QU
CA-QU
video thumbnails placeholder
CA-QU
CA-QU
Play Video
CA-QU
CA-QU
video thumbnails placeholder

Epoxy resin, quartz and a phial of hardener. Opt.8 ETA Assessed. Epoxy resin, quartz and a phial of hardener. Option 8 ETA Assessed

Chemical plug in a capsule for medium and high loads, consisting of an epoxy-acrylate resin, quartz and a catalyst. It is approved for structural fixings in non-cracked concrete (ETE Option 8). It can be used with M8 – M24 studs, both indoors and outdoors. It is suitable for static or quasi-static loads.
> CAD Data

ASSESSMENTS AND CERTIFICATES

+ info
TDDU22BI9312 ETA UN 08 0350 ETA UN 08 0350 SZ6
EKOU4BI8300 HO A A SZ7
EKOU16BI9347 HO CE 08 CE 2008 SZ7
CODESIZEMin. Order Qty.Pcs. x jarPcs BoxPcs MasterboxEANTechnical info.
CAQU0088 x 80 Ø1000105008423533046505
  • tfix - Max. fixture thickness17
  • SW - Installation key13
  • df - Ø Element to fix9
  • Tins - Torque (Nm)10
  • hef - Effective depth80
  • hnom - Min. anchor depth80
  • h1 - Drill hole depth min.80
  • d0 - Ø Drill10
  • hmin - Min. substrate thickness110
  • L - Lenght80
CAQU01010 x 90 Ø1200105008423533046604
  • tfix - Max. fixture thickness25
  • SW - Installation key17
  • df - Ø Element to fix12
  • Tins - Torque (Nm)20
  • hef - Effective depth90
  • hnom - Min. anchor depth90
  • h1 - Drill hole depth min.90
  • d0 - Ø Drill12
  • hmin - Min. substrate thickness120
  • L - Lenght90
CAQU01212 x 110 Ø1400102008423533046703
  • tfix - Max. fixture thickness32
  • SW - Installation key19
  • df - Ø Element to fix14
  • Tins - Torque (Nm)40
  • hef - Effective depth110
  • hnom - Min. anchor depth110
  • h1 - Drill hole depth min.110
  • d0 - Ø Drill14
  • hmin - Min. substrate thickness140
  • L - Lenght110
CAQU01616 x 125 Ø1800102008423533046802
  • tfix - Max. fixture thickness44
  • SW - Installation key24
  • df - Ø Element to fix18
  • Tins - Torque (Nm)80
  • hef - Effective depth125
  • hnom - Min. anchor depth125
  • h1 - Drill hole depth min.125
  • d0 - Ø Drill18
  • hmin - Min. substrate thickness160
  • L - Lenght125
CAQU02020 x 170 Ø25006608423533046901
  • tfix - Max. fixture thickness66
  • SW - Installation key30
  • df - Ø Element to fix22
  • Tins - Torque (Nm)120
  • hef - Effective depth170
  • hnom - Min. anchor depth170
  • h1 - Drill hole depth min.170
  • d0 - Ø Drill25
  • hmin - Min. substrate thickness220
  • L - Lenght170
CAQU02424 x 210 Ø28006608423533047007
  • tfix - Max. fixture thickness62
  • SW - Installation key36
  • df - Ø Element to fix26
  • Tins - Torque (Nm)180
  • hef - Effective depth210
  • hnom - Min. anchor depth210
  • h1 - Drill hole depth min.210
  • d0 - Ø Drill28
  • hmin - Min. substrate thickness260
  • L - Lenght210
CAQU03030 x 280 Ø35006308423533022455
  • tfix - Max. fixture thickness22
  • SW - Installation key46
  • df - Ø Element to fix33
  • Tins - Torque (Nm)300
  • hef - Effective depth280
  • hnom - Min. anchor depth280
  • h1 - Drill hole depth min.280
  • d0 - Ø Drill35
  • hmin - Min. substrate thickness360
  • L - Lenght280
  • Air conditioning units
  • Balcony railings
  • Road railings
  • Concrete building under construction
  • Industrial shelving
  • Street lights
  • Presses
  • Overhead cranes
  • Overhead cranes
CA-QU
icon book
Technical Sheets
FT_CAQU_en_rev10.pdf
FTA_CAQU_en_rev4.pdf
FS_CAQU_en_rev7.pdf
icon security
Assessments
ETA_CAQU_en_rev3.pdf
icon camera
Multimedia
Video
icon table
Declaration of Performances
DoP_CAQU_en_rev0.pdf

related products

EQ-A2

EQ-A2

Stud bolt for chemical anchor, with nut and washer. A2 Stainless steel
EQ-A4

EQ-A4

Stud bolt for chemical anchor, with nut and washer. A4 Stainless steel
EQ-AC

EQ-AC

Stud bolt for chemical anchor, with nut and washer. Zinc-plated
